As of 11 October 2026. Configuration below is illustrative FortiOS 7.6 syntax and has not yet been validated in our lab. Failover times depend on your timers, links and providers, so measure them rather than relying on any published figure.
Two internet links are not automatically resilient
Many offices pay for a second ISP and discover during the first outage that both circuits ran through the same duct, the same exchange or the same upstream carrier, or that traffic did not move because nothing was checking whether the internet beyond the modem was reachable. SD-WAN solves the steering problem; design and testing solve the rest.
Design the physical diversity first
- Different last-mile media where possible, for example fibre plus a licensed wireless or 5G link, rather than two fibres in the same trench.
- Different building entry points and exchanges. Ask each provider for the route and the exchange they terminate on; get it in writing.
- Different upstream carriers. Two resellers of the same backbone fail together.
- Separate power paths for both modems or ONTs and the firewall, on UPS.
How FortiGate SD-WAN decides a link is down
On a FortiGate, each WAN interface becomes an SD-WAN member, members are grouped into zones, a performance SLA (health check) probes a target over each member, and SD-WAN rules choose which member carries which traffic. Fortinet documents three health-check timers under config system sdwan › config health-check:
| Setting | Meaning | Default |
|---|---|---|
interval | Milliseconds between probes (20–3600) | 500 |
failtime | Consecutive failed probes before the member is marked dead | 5 |
recoverytime | Consecutive successful probes before the member is marked alive again | 5 |
From those, Fortinet gives the detection times:
alive → dead = failtime × interval / 1000 seconds
dead → alive = recoverytime × interval / 1000 seconds
Defaults: 5 × 500 / 1000 = 2.5 s to declare a link dead
5 × 500 / 1000 = 2.5 s to declare it alive againFast detection is not always better. A short recoverytime on an unstable link makes traffic flap back and forth; a long one keeps traffic off a repaired link for minutes. Fortinet’s own worked example (interval 2,000 ms, failtime 2, recoverytime 60) takes 4 seconds to declare a link dead and 120 seconds to bring it back. Separately from dead/alive, SLA thresholds for latency, jitter and packet loss mark a link out of SLA; packet loss is measured over the last 100 probes, so recovery from heavy loss is gradual. Fortinet notes that from FortiOS 7.6.4 a member recovering from dead goes straight to in-SLA once its metrics are within thresholds.
Illustrative configuration
Illustrative example (FortiOS 7.6 syntax, not lab-validated). Interface names, the probe target and thresholds are placeholders. Probe a target beyond each provider’s network, not the provider’s own gateway, or a failure upstream of the gateway will go unnoticed.
config system sdwan
set status enable
config zone
edit "internet"
next
end
config members
edit 1
set interface "wan1"
set zone "internet"
set gateway <ISP-A-gateway>
next
edit 2
set interface "wan2"
set zone "internet"
set gateway <ISP-B-gateway>
next
end
config health-check
edit "internet-sla"
set server "<probe-target-1>" "<probe-target-2>"
set protocol ping
set interval 500
set failtime 5
set recoverytime 10
set members 1 2
config sla
edit 1
set latency-threshold 150
set jitter-threshold 30
set packetloss-threshold 5
next
end
next
end
config service
edit 1
set name "business-apps"
set mode sla
set dst "all"
config sla
edit "internet-sla"
set id 1
next
end
set priority-members 1 2
next
end
endBefore change: export the current configuration. Rollback: restore the backup or disable the SD-WAN rule, which returns traffic to the default route behaviour.
Test it like an outage
Run each test in a maintenance window with a continuous, timestamped ping and a long-running application session (for example a video call or a large download) open from a test laptop.
| Test | How | Record |
|---|---|---|
| Hard failure | Unplug the primary WAN cable | Seconds until ping recovers on the secondary; whether the video call survived |
| Upstream failure | Block the probe targets on the primary path only | Whether the SLA marks the link dead even though the cable is up |
| Degradation | Add latency or loss with a link emulator, or test during a known bad period | Time to move traffic out of SLA; any flapping |
| Recovery | Restore the primary link | Seconds until traffic returns; whether it flaps |
| Inbound services | Reach published services (VPN, web) from outside during failover | Whether DNS, NAT and certificates work on the secondary IP |
Repeat each test at least three times and keep the results. Those numbers, not the vendor defaults, are what you can tell the business. Inbound services are where failover most often disappoints: a site-to-site VPN or published server bound to the primary IP will not follow the outbound traffic unless it has been designed to.
Sources
Primary sources used for this article (checked 11 October 2026):
- Fortinet Community: Understanding SD-WAN transition timers
- Fortinet: FortiOS 7.6 Administration Guide, SD-WAN performance SLA
